Snap Action 3-to-9 Wiring Block Connector
❌Kan nageleverd worden
- Artikelnummer
- ADA5614
Omschrijving / Snap Action 3-to-9 Wiring Block Connector
Snap action blocks are perfect when you have to quickly wire up a bunch of free-hanging components, and you don't want to solder. They're much easier to use than wire nuts, and of course they are reuse-able and do not require any crimping!
This is a 3 to 9 wire block: there are three separate inputs, and three sets of three outputs. They're color coded so easy to follow, the green yellow and red inputs match the colored outputs. Great for basic power or data fan-outs.
Each block connector has a metal block inside and levers that snap open and close to bind stranded/solid-core wire from 12 AWG down to 24 AWG. No screwdrivers or crimpers required, making them super handy for free wiring. Each block is marked to handle up to 32A at 250V, but we haven't tested them at such high power uses - we're selling them for maker projects that would be 10A at 24V max.
Meer informatie
| Artikelnummer | ADA5614 |
|---|---|
| Garantie | 2 Jaar |
| Korte Beschrijving | Adafruit artikelnummer 5614. Dit artikel bestellen wij wekelijks bij Adafruit. Wanneer het niet direct uit onze voorraad leverbaar is, bedraagt de verwachte levertijd circa 1 tot 2 weken. Indien het artikel op voorraad is, kunnen wij het uiteraard direct leveren. |
